Honeywell W8735D1009 telephone access module (tam)
With the Telephone Access Module (TAM) from Honeywell, homeowners can adjust the comfort levels in their home, cabin or vacation retreat by simply using a telephone.
A wide range of devices will interface with the TAM, including:
• W8635 Equipment Interface Module (EIM)
• W8703 Damper Interface Module (DIM)
The Telephone Access Module is perfect for homeowners who travel often, have vacation properties or simply want the peace of mind of remote monitoring. The TAM can monitor outdoor temperature and humidity when the proper sensors are available. Battery back-up informs the user of power outages.
The TAM is also equipped with helpful diagnostic features:
• Last 10 time-stamped alerts with alert codes for contractors
• Zones can be named to better access information
• Multiple telephone numbers can be entered to ensure alerts are received
• Repeated dial-outs until alerts are acknowledged
• Alert priorities can be set to ensure critical alerts are received immediately
The bottom line for the Telephone Access Module is peace of mind for the homeowner, which can lead to additional opportunities for you. Alerts are easily set up using the voice menu and phone keypad, and can be set up to notify the homeowner and/or you.
• High/low outdoor temperature (if sensor is available)
• Humidity (if sensor is available)
2 Channel Telephone Access Module
The W8735D Telephone Access Module (TAM) provides remote telephone access to the HVAC system when used with EnviraCOMâ„¢ enabled controls
Up to three dial-out numbers, power outage duration, zone names, enable/disable filter altert, and enable/disable dial-out alert.
9 zones per channel; 2 channels; 18 total zones
Compatible with Discharge Air Temperature
1/D, 2/R, 3/B, Aux In, Aux Out
10 in. high x 5 in. wide x 2 in deep.
254 mm high x 127 mm wide x 51 mm deep
No. 6 screw and wall anchors supplied in bag assembly
Operating Humidity Range (% RH)
C7089B Outdoor Temperature Sensor
W8703A Damper Interface Module
TH5320 FocusPRO EnviraCOM Thermostat
50022037-001 Enciracom Outdoor Temperature Sensor
AT120 General Purpose 20VA Transformer
T8365 Microelectronic Communicating Programmable Thermostat
Communication and Battery LED's
Approvals, Federal Communications Commission
FCC rules: Part 68 and Part 15
EnviraCOM enabled thermostats and combustion controls
