Tek 3B3 manual in 2 res w/ A3, A4, +txtsrch, +extras
Tektronix 3B3 Plugin Manual in both Very High and in Standard Resolution PDFs on CD
Why settle for just one resolution? You get them both!
For page samples from this specific manual, click HERE.
Also includes the Tektronix Semiconductor Parts Catalog, plus an interesting and informative Articles PDF at no additional charge!
These manuals cover the Tektronix 3B3 Plugin for the 561A, 564 and 567 Oscilloscopes. They are scanned from the original manufacturer's manual. The scans came out well, and all information available in the original manual is available here.
Three PDFs of the manual are provided, in two resolutions. One is:
Text with Drawings at 600dpi black and white
Schematics at 600dpi black and white
Text with photos at 600dpi grayscale with contrast adjusted
Any schematics, board overlays w/color at 600dpi 256 colors
Both resolutions are bookmarked, hyperlinked, and feature both the chapter-page and sequential page numbering systems. The fast "bench resolution" PDFs, which are designed primarily for research as opposed to printing, are also text-searchable.
Foldout pages are supplied as A4 (8-1/2x11") pages within the "main" manual for ease of printing, and are also supplied in a separate "foldouts.pdf" document in A3 (17x11") for they who prefer them. The pages can be printed as needed or the information taken directly from the computer screen. If any exist, technical notes made by engineering and technical personnel are retained in this document.
The "very high" or "reproduction grade" resolution looks nice, but for many purposes uses excessive resources. Limiting yourself to that is kind of like riding to work every day on a tractor. You can copy the large file to the hard drive in an attempt to achieve maximum performance, but having that be a necessity is certainly of no benefit to you. Therefore, although it's great to have this resolution for those times you need higher definition (printing, mainly), we include a second scan in standard resolutions for daily research and use on the bench.
The second scan is done in resolutions that vary depending on individual page content, but are never higher than needed to produce useable quality, quickly navigable files that will do the job without consuming more time and resources than are needed.
On the CD you'll receive the large "very high resolution" or "reproduction quality" file, plus the smaller, faster and often more useable text-searchable version. ALL original manual pages are supplied. "Marketing" vendors proudly advertise page counts and file sizes, but since those counts and sizes are so often artificially inflated with advertising and/or blank pages, we refrain from playing such games and instead assure you that these manuals are complete and are scanned in the specified resolutions.
