Summation sigmaseries 2010A testframe ate ats *complete


Summation SigmaSeries 2110A ATE TestFrame
Includes CPU, Memory Board, Power Supply & Analog/VME Motherboards
The Summation 2110A TestFrame integrates up to 12 SigmaSeries function modules in a 7" high rack mountable chassis. It provides a common physical and electrical environment for these modules in addition to a programmable user-interface. Four internal buses provide the communication among the TestFrame, the modules and any external sources.
The TestFrame's front and back panels provide extended operator control. The fronts panel's blue fluorescent display is capable of displaying any of the 96 standard ASCII characters in its two 40-character rows, making it easy to send error information and prompts to the operator. Front panel keys f1-f5 are arranged so that prompts can be displayed directly above them. By programming any of the front panel's seven function keys, interrupts can be sent to the test program by a press of a key.
Included is the CPU, Memory Board, Power Supply, and VME/Analog Motherboards. The system passes self-tests and awaits instructions from the computer.
* Imbedded 68000 microprocessor
* 4 Mbytes of internal memory
* Single, heavy duty function module power supply
* 12 slots for instrumentation function modules (expandable to up to 23 slots with ExpansionFrame)
* Comprehensive internal bus structure
* IEEE-488 controllable via DMA interface
* Up to 10 TestFrames per system
Standard 19" wide x 21.2" deep. Approximately 50 lbs (22.7 kg) without modules.
Memory Board P/N: 1700-102991 Rev. A (9000-101866)
CPU P/N: 1700-102863 Rev. B (9000-101864)
~ International: *International Surface Parcel (4-6 weeks) or XpressPost International (5-9 Business days) - $199.95 & $349.95 respectively
PHOTOS BELOW ARE OF THE ACTUAL ITEM
