Ram-type edm, charmilles D10
Used Machinery and Machine ToolsUsed MachineryUsed Machine ToolsThousands of Used Metalworking and Plastic Machines & New Machine Tools Photos, Full Descriptions and Prices - Fast & Easy
* Manual Lathes, Mills, Drills, Saws
* Grinders, Hones, Finishing
* Ovens, Furnaces & Environmental
CHARMILLES RAM TYPE EDM MACHINE
MODEL: D10 S/N: 50356 NEW: 1980
AVERAGE WEIGHT (WITH TABLE, WITH RESERVOIR): 280 KG
SUPPLY VOLTAGE: 220/280/440V-3 PHASE, 50/60 HZ
GENERATOR SELECTION: 25 AND 50 A
FLOOR SPACE OCCUPIED WITH R-80 RESERVOIR : 59" X 31.5"
LINEARITY OF MOVEMENT WITHIN: (.0008")
LINEARITY OF MOVEMENT WITHIN: (.0002")
REPEATABILITY WITHIN: (.0004")
MAXIMUM ELECTRODE WEIGHT (MECHANICAL FIXING): 66 LBS.
LONGITUDINAL & TRANSVERSAL TRAVELS: 7.9" X 4.7"
LINEARITY OF MOVEMENT WITHIN: (.0004")
POSITION REPEATABILITY: (.0008")
INSIDE DIMENSIONS: 20.5" X 13.8"
RECOMMENDED DIELECTRIC RESERVOIR: R-80
MICROFIN FINE FINISHING OPTION
** EXCELLENT CONDITION & APPEARANCE **
** INSPECT IN OUR HARRISON, N.J. WAREHOUSE **
Machine Location: HARRISON, NJ
