Allen bradley micrologix 1200 plc (1762-L40BWA) 24I 16O
Allen Bradley Micrologix 1200 PLC (1762-L40BWA) - 24 Inputs, 16 Outputs
As shown, Includes Installation Manual and Micrologix 1200 PLC (1762-L40BWA) 24 Inputs (DC), 16 Relay Outputs
This item was purchased NEW and sat on the shelf as a backup for an identical unit which was in service. It had a program loaded in it, but it was never used. You will not find a cleaner unit.
The MicroLogix 1200/1762 system provides functionality using the proven MicroLogix and SLC family architecture. The 6K-word memory provides for a maximum program of 4K words and maximum data of 2K words with 100% data retention. The flash upgradeable operating system lets you upgrade system software without replacing hardware.
The MicroLogix 1200 controller is designed to optimize panel space. Just 90mm (3.54 in) high (110mm high including mounting tabs) and 160mm (6.30 in) wide include processor, embedded inputs and outputs, and power supply. Expansion I/O modules add only 40mm (1.57 in) each in width.
A range of I/O and communication options let you configure a MicroLogix 1200 controller for a variety of applications:
40 built-in I/O. The inputs are 24V dc (sink or source). Outputs are relay contact.
Add up to 96 I/O in up to 6 digital and/or analog I/O modules (within the limits of power supply capacity, for a total of 136 I/O maximum).
Wide range of communication options:
DF1 full- or half-duplex, DF1 Radio Modem, Modbus RTU slave and RTU master. Communication interface modules support DH-485, DeviceNet, and EtherNet/IP.
MicroLogix 1200R controllers also provide a Programming / HMI port with fixed communication parameters to provide an additional means to communicate to the controller.
High Functionality—The MicroLogix 1200 / 1762 system provides powerful features that let you tackle tough applications:
20k-Hz PTO (Pulse Train Output) or PWM (Pulse Width Modulation).
6K-word non-volatile memory (4K-word maximum program, 2K-word maximum data).
2 built-in trim potentiometers.
optional memory, real-time clock, or memory/real-time clock module.
powerful instruction set with support for PID and ASCII.
uses RSLogix 500 programming software.
field-upgradeable flash operating system.
