Kwh "smart" power meter electric submeter 120/240V 100A
•• NEW!!-This is a revolutionary **Smart Meter** at an extraordinary price!!!
•• Built-in data storage and RS-485 Serial Communication for reading kWh usage remotely!!
•• FREE PC, Linux and Mac software to read the meter kWh data remotely!!
•• Connect to your computer via 2-wire RS-485- - -Easy to connect 2-wire, daisy-chained network!
•• Up to 32 meters can connect over 4000 feet to one serial or USB port on your computer!
•• Low-cost, tested, compatible, USB and serial port converters available!
•• Or - - Connect up to 32 meters to one $65 Internet-connected device for world-wide access!
•• Each meter has it's own network address!
•• State of the art, solid-state, digital energy meter
•• Compact, easy-to-install design
•• Monitor all critical circuits in your home or business
•• Pulse output-800 pulses per kWh
•• Not available anywhere else!! This is a TOTALLY unique product!
•• Watertight enclosures available
This is a brand new kWh meter design, manufactured for EKM Metering, the most advanced type electronic KWH meter available on the market, model EKM-25IDS-N, 3 wire, 100 amp version. These were made specifically for U.S. 3-wire 120/240 (range: 84-168/156-312) volt single phase (2 phase) metering. They require 156 to 312 volts for operation. Installation is easy, since the meter is completely self contained, no external current transformers (CT's) or other extras as with many other electronic type meters. However, installation should only be performed by a knowledgeable, qualified electrician. The 2 "hot" service wires are simply passed through tubes in the meter housing (3/8" diameter), and 2 screws are tightened to pierce the wiring to power the meter-less than 1 watt required. Installation and instruction manual included. Dimensions are approx. 3"w x 4"h x 2.5"d.
The meters have a non-resetable, 5 digit LCD readout with hundredths, and read directly in kWh, no conversion factors as with some other electronic meters. They also have built-in kWh data storage which is readable via a 2-wire (with ground) RS485 serial connection to your PC (connections A,B and G in the photo). In addition, they have a built-in PULSE OUTPUT, 800 pulses per kWh. They are perfect for remote and automatic meter reading (AMR) applications.
Use these meters to measure and keep track of kilowatt hours and energy usage for sub panels or individual pieces of equipment. I can supply any number of these you need.
Although the TCP/IP to RS-485 converter is quite a bit more expensive, I highly recommend it. With the meters connected to this device, and the device connected to your LAN or router, you will be able to read the meters from anywhere, not just locally, but anywhere in the world!!! **** If you want to see how this works, download the software and run the appropriate application from the downloaded folder. You will be able to read my test meters from your PC, Linux box, or Macintosh running OS X. These meters are connected to the TCP/IP to RS-485 converter at my test site.
Also available in 120 volt version and in a "Smart" version-with RS-485 serial communication and on-board data storage.
If you need other types of kWh meters-
120 volt models or external current transformer models,
please take a look at my other items for sale!
100% Satisfaction Guaranteed!! Return within 30 days if you are not completely satisfied. One year warranty from the manufacturer.
