Hp/agilent 3048A phase noise measurement rack system
HP/Agilent 3048 Phase Noise Measurement System
NIST CAL/CERT 90 Day Warranty* 5 Day ROR*
Please review item Description & Condition
MANUFACTURER'S Specifications:
* 3561A - Frequency range: 125uHz to 100kHz; Dynamic range: 80dB; Amplitude accuracy: ±0.15dB; Flexible zoom analysis for frequency spans as narrow as 0.25Hz (with 0.000640Hz resolution); Direct digital plotting; RMS, time, and peak averaging; Light weight and portable; Softkey menu driven software; 1/1 and 1/3 octave analysis; Built-in 4mA current source for integrated circuit piezoelectric accelerometers; Call/email for price and availability of the following option: 001-Extended Memory.
* 11848A - Phase Noise Interface is an integral component in 3048 system, contains the phase detectors and phase-lock loop circuitry, with 3561A dynamic signal analyzer measurement software, A variety of signal generators can be added to the system to provide a low-noise reference signal up to a frequency of 2.56GHz; Call for further specifications on the 11848A.
NOTE - Option 201 is installed and adds 1.6 to 18GHz input
* 11729C - Carrier Noise Test Set is an integral part of a phase noise measurement system. The HP 11729C can perform the following operations up converts an external (or internal) reference signal, down converts the signal under test to an intermediate frequency (IF). The phase demodulates phase noise of the test signal using the Phase Detector Method; frequency demodulates the phase noise of the test signal using the Frequency Discriminator Method.
Dimensions: 62"H x 24"W x 31"D
Weight (estimate): 200# (w/Manuals)
Unit will be Calibrated to meet manufacturer's specifications in our ON-SITE NIST lab by one of our expert certified technicians.
This unit comes from a working large-scale industrial/lab environment.
F the item (3048 rack system w/components and manuals shown) used with NIST CAL/CERT, 90 day warranty* and 5 day ROR* minus s/h both ways
F no other accessories, manuals, modules, probes, orig. packing, etc.
Contact via E-mail for more information.
HP/Agilent 3048 Phase Noise Measurement System
NIST CAL/CERT 90 Day Warranty* 5 Day ROR*
Image Gallery (click thumbnail for larger view)
IMAGES ARE NOT NECESSARILY THE SERIAL NUMBER/UNIT YOU WILL RECEIVE
Item is sold without accessories probes, power cord, software, carrying case, etc.) unless specifically mentioned in the above description.
No implied or expressed warranty unless otherwise stated.
Item descriptions are as accurate as possible but may contain errors.
Photo images are of the actual item. What you see is what you get.
Technical information is provided as available.
We reserve the right to rescind any sale if not contacted within 3 days.
We currently have skids of equipment that have yet to be placed in inventory, and we are looking to move items quickly. We need to make room!
If you don't see what you need, contact us. Your much-needed piece of technology may still be waiting for a spot on our shelves!
IN THE RARE EVENT A SOLD ITEM CAN NOT BE CALIBRATED BEFORE DELIVERY: Before our items are put into inventory they are lightly examined in our lab for operational status. Some are then stored in the warehouse until sold at which point it is brought back into the lab for a complete testing and the issuing of the 'CAL/CERT'. Others already have a 'CAL/CERT' issued before being placed in the warehouse. Though rare it is possible for the item to be found during the 'CAL/CERT' process to have a defect not apparent in the initial operational examination. At this point the item is fully reconditioned with the defect corrected... HOWEVER there are times the item my not be repairable or the manufacturer no longer has a part needed to correct the problem, OR the part may take a day or 2 or a week to arrive. We stock most parts here but there are the times we need to order it and it could happen the part is unavailable. We have multiple units of most of these items and can find one that is completely operational or take a part from one to fix the other.
