19" ENGINE LATHE, LeBlond REGAL SERVO-SHIFT I
19" ENGINE LATHE, LeBlond REGAL SERVO-SHIFT I
19" x 54" LEBLOND SERVO SHIFT ENGINE LATHE
MODEL: 19" REGAL, S/N: 11E-341, NEW: 1979
SWING OVER BED .................... 19-1/4"
SWING OVER CROSS SLIDE ............ 12-1/4"
DISTANCE BETWEEN CENTERS .......... 54"
SPINDLE NOSE ...................... L2
HOLE THRU SPINDLE ................. 3-1/16"
SPINDLE SPEED RANGE (12) .......... 40 - 1600 RPM
LONGITUDINAL FEED RANGE (48) ...... .0018" - .104" IPR
CROSS FEEDS HALF THE VALUES OF LONGITUDINAL
THREADING RANGE ENGLISH (48) ...... 2 - 112 TPI
THREADING RANGE METRIC (40) ....... 0.25 - 12 mm
TAILSTOCK SPINDLE TRAVEL .......... 7"
TAILSTOCK SPINDLE TAPER ........... #4 MT
APPROX WEIGHT ..................... 4,450 LBS
APPROX DIMENSIONS ................. 113"L x 40"W x 51"H
- REPLACEABLE HARDENED BED WAYS
- 12†DIA. CUSHMAN 4-JAW CHUCK
- 12†DIA. 3-JAW UNIVERSAL CHUCK
- 6†CAP.ROLLER TYPE 3-POINT STEADY REST
- COOLANT WITH REAR SPLASH GUARD
- 10 H.P. 3/60/230-440 VOLT MOTOR WITH CONTROLS
- WIRED FOR 3/60/230 VOLT OPERATION
Machine Location: WILMINGTON, DE
