Optrel cosmic copper satellite welding helmet K604
YOUR SOURCE FOR WELDING SUPPLIES
WELDING EQUIPMENT - SAFETY SUPPLIES
ARCAIR SLICE PACKS - LENCO SPOT
________________________________________________________________________________________________
OPTREL SATELLITE WELDING HELMETS
Optrel Satelliteâ„¢ Welding Helmet
Several LCDs provide protection. Special filters provide you with permanent protection from UV and IR radiation.
Eliminates the effects of ambient light. By moving the sensor frame the angle of detection will open up, necessary for over head welding Power supply
optrel® OSE Satellite has a proven solar cell technology which ensures the supply of power.
The front cover lens equipped with an elastic gasket prevents the infiltration of gas, fume and particles.
Using this sliding switch, the opening delay can be conveniently adapted to your requirements.
This knob can be used to select the shade level required: selections can be made in two ranges between DIN 5 and DIN 9 and 13. Therefore, a wide range of applications is opened up.
This push button can be used to change into grinding mode (DIN 4) without taking off the helmet.
(Automatically reset after approx. 10 minutes.) Range of shade levels
This sliding switch can be used to select the range of shade levels, i.e. between DIN 5 and 9 or DIN 9 and 13.
To meet all different welding applications on different welding places you have the possibility to adjust the sensitivity to your need.
Cartridge type 2 shade level settings of DIN 4/5 and DIN 4/9 - 13 continuously variable manual settings between DIN 5-9 and DIN 9-13
All shade cartridge controls and settings are conveniently on the outside!
Variable shade range selection and adjustment "5-9 or 9-13"
Selectable On/Off shade 4, grinding function
Spherical cover plate for superior optical clarity
2 Year Warranty on ADF cartridge
Controls for helmet as shown schematically above.
Simply press the oversize shade control button and the auto darkening filter is locked in to a shade 4. This eliminates filter flickering while grinding or brazing. Both are now possible without helmet removal. Depress control button again to reset ADF
This sliding switch can be used to select shade ranges of 5 - 9 and 9 - 13. Choose your range and then adjust to the appropriate shade using the shade level control knob
Adjust this control knob to select the shade within settings of 5 - 9 or 9 - 13. Selections can be made according to the welding process, making this one of the most versatile helmets on the market
Factory set at red dot for most procedures. Adjustable to meet different welding applications including micro plasma, plasma cutting, and low amperage TIG welding to name a few. Match the sensitivity level to suit your specific needs
By using the sliding switch the time delay from dark to light can be adjusted to your individual requirements
Optrel's proven solar technology ensures a continuous power supply while also eliminating the need for on / off switches and untimely / costly battery changes
Eliminate the effects of ambient light. Simply slide the sensor bar up and the angle of detection will open from 60 degrees to 120, which optimizes performance during low current and over the head welding. Keep it down and reduce the chances of a near by arc darkening your lens.
Several LCD's and special filters provide permanent shade 14 protection from dangerous UV and IR radiation, even in the unlikely event of total filter failure
Variable Shade 5-9 or 9-13
