Dickey 4000 hydraulic rotary tube end trimmer
DICKEY MODEL 4000 HYDRAULIC ROTARY TUBE END TRIMMER*
Maximum Diameter: 4" O.D. x .125"
Clamp Pressure @ 1100 PSI: 13,800 Lbs
Trimming Pressure @ 750 PSI: 6,200 Lbs
Trim Stroke: 1"
Main Spindle Speed (Adjustable): 300 RPM (Max.)
Distance Spindle Center to Floor: 42"
EQUIPPED WITH:
Allen-Bradley SLC-500 PLC Programmer
Continuous Running Rotary Head Face Plate
Adjustable Cycle Time Control
Fully Automatic Sequences
5 HP AC Main Drive (Spindle) Motor
5 HP AC Hydraulic Pump Motor
Self Contained Hydraulic Power Unit
Electrical Controls
Dual Palm Button Operations
Approximate Overall Dimensions: 72" L-R x 50" F-B x 79" H
Approximate Weight: 4,000 Lbs.
Serial Number: 635 (New 1984)
P2 F.O.B. Elk Grove, IL - $ 17,500.00
* PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION
